NOTE: Once connecting this harness and your unit works and has sound, if after setting canbus there is no communication - then your old system was using the old head unit frame to complete the circuit for the steering wheel controls. This must be rectified by providing an earth for the steering circuit
WARNING: If your OEM camera is 6 volt, do not plug it into our grey plug (in the red box in the below image) or it will cut off the sound. You will need a retention harness or use our TEYES Sony Lens camera.
WARNING: If the reverse camera comes on all the time and you are having taco drop out / flashing center diff / ABS/ Traction light, disconnect the 2 wire black plug in the yellow square box in the image below
WARNING: If the AC module keeps having intermittent issues such as - the fan cutting in and out, or the screen with flash on/off for 1 or 2 seconds or both, disconnect the CAN plug as demonstrated in this image below.
IMPORTANT - If your head unit is has 360 camera system and looks like the below unit - use this harness instead
NOTE: If your unit is not turning on, check your negative connection. Below is from a Mitsubishi challenger 2014 which the Red/Silver wire did not align with the negative pin.
